The DCFT55 is a fully automatic integrated roll – to – sheet laminating machine. The equipment is compatible with both roll – type Coverlay Film (CVL) feeding and sheet – type Coverlay Film (CVL) feeding. It is also compatible with Coverlay Films that are either laser – cut or die – punched. For FPC, it features automatic sheet – type loading and unloading.
When using roll – type Coverlay Film (CVL) for feeding, the processes include semi – cutting, cleaning, peeling off the PI film, alignment, laminating, and inspection. When using sheet – type Coverlay Film (CVL) for feeding, the processes involve the loading suction cup, peeling off the release paper, alignment, laminating, and inspection.
Optional function: There is a risk of waste residue in laser cutting. The laminating process will be carried out after the linear scanning camera detects the waste.
| Specifications/Model | DCFT55 |
| CVL Dimensions Thickness | CVL Roll Feeding/CVL Sheet Feeding Min: 260mm × 100mm Max: 260mm × 500mm CVL Thickness: 25μm-100μm |
| FPC Dimensions Thickness | Min: 260mm × 200mm Max: 260mm × 500mm FPC Thickness: 0.036-1mm |
| Feeding Method | FPC Sheet Feeding; CVL Roll Feeding or CVL Sheet Feeding |
| Machine accuracy | ±0.05mm (excluding FPC and CVL expansion and contraction) |
| Bonding accuracy | ±0.1mm (including FPC and CVL coating, machine accuracy + FPC and CVL expansion and contraction / 2 or CVL alignment deviation ≤ 0.1mm) |
| Lamination Speed | 360-400 sheets/hour Single Sticking 400-450 sheets/hour Multiple Sticking |
| Power Consumption | AC380V ± 10% 50Hz, 12kW |
| Air Supply | Power Consumption: 0.5-0.7mPa, Air Consumption :120L/Min |
| Equipment Dimensions | 3150mm(L) × 1550mm (W) × 2215mm (H) (including FFU) |
| Weight | 2500kg |
